Flow Meter

♦Supertech brand Flow Meter ,whose material of the body is made of

alloy alminum, with structure of strainless steel bush and four piston Positive Displacement.

♦Novel Appearance,Small Size,High Reliablity,High Precision, Firm Structure,

Good Wearability,FM4 Flow Meter is built in intelligent pulser,

60 pulses or 100 pulses for option;but FM4 FlowMeter without pulser.

Automatic Nozzle

♦Flow Rate:0-120L/m(113/16")/0-90L/m(1")

♦Working pressure: 0.18Mpa

♦Color:Red/Green/Blue/Yellow/Black/Gray

♦Body:Aluminum

220V Motor

♦Voltage:220V 50Hz,single phase

♦Power:750W(1HP)/1KW

♦Function: offer power

♦Characteristic:Oil resistant

♦Advantage:stable quality

380V Motor

♦Voltage:380V 50Hz,single phase

♦Power:750W(1HP)/1KW

♦Function: offer power

♦Characteristic:Oil resistant

♦Advantage:stable quality

Ambient temperature

-25℃~+55℃

Humidity

≤95%

Flow meter type

optional

Flow meter accuracy

≤0.3%

Motor power capacity

1HP（0.75kw）

Nozzle

auto shut-off

Repeating tolerance

≤0.15%

Suction distance

6m

Inlet pressure

≥54kpa

Outlet pressure

≤0.3Mpa

Voltage

220v/380v

Noise

≤80dB

Control type

solenoid valve control

Pump flowrate

55±5

Max flow

80L/min
